Sequence numbers
The segments into which a bit stream is divided are identified by the
number of the first octet in the segment. This number is derived from
the octet's position in the stream by adding to it the initial
("random") number associated with the connection. The choice of this
number has to guarantee that this or a future connection between the
same pair of hosts will not receive a segment with the same sequence
number but from a different session.
The mechanism to achive this random initial numbering is through a
counter ("clock") whose value is used as the initial sequence number
upon opening a connection. There is always a danger of a "phantom"
segment cycling in the network that appears at the receiver with all
the right identifications, including the sequence number, but
belonging to some previously transmitted bit stream.
The following diagram indicates the importance of preserving the proper ratio between the clock frequency and the data rate in the bit stream.
The double life time of a segment, T, defines a forbidden region for
certain sequence numbers that can be confused by the receiver (if a
new connection were to be established). There are two extreme situations:
- The data stream is transmitted faster than the increments of
the clock (in which case a subsequent sudden closing and opening of
the connection may result in confusing segments with the same sequence
number. (We call this "entering the forbidden region from below.")
- The data stream is transmitted too slowly, so that the clock
starts recycling the sequence numbers being used ("entering the
forbidden zone from above".)
In TCP, the sequence number initialization problem is resolved by
using a 16-bit counter which is incremented by (an equivalent of) 1
every 4 microseconds and does not "recycle" numbers for over four hours.
